Technical data
USER MANUAL FPC 200 - 3/2017 171
Digital (relay) outputs
Switching capacity
AC
8 A; UL: 10 A; 15 A (max. 4 s)
DC 30 V
8 A (resistive load)
DC 48 V
2 A (resistive load)
DC 110 V
0,4 A (resistive load)
DC 220 V
0,28 A (resistive load)
Limiting making current breaking
capacity
15 A; max. 4 s, duty factor 10 %;
max. 2000 VA
Number of switching cycles
electrical 100 k, mechanical 1 M
Maximum switching voltage
AC/DC
250 V; 50 Hz - 60 Hz
Maximum number of simultaneously
activated relays
8
Power supply burden of each active relay
0,5 W
Protection
dustproof
Galvanic isolation
AC
3,5 kV; 50 Hz; 1 min
Communication – RS-485
Connector
rear, screw connector
Cable
120 Ω STP or UTP (twisted pair)
Transfer speed
1200 bit/s - 115,200 bit/s
Range
approx. 1200 m (according to EIA-485)
Galvanic isolation
AC
3,5 kV; 50 Hz; 1 min
Communication – RS-232
Connector
rear, DB9F
Transfer speed
1200 bit/s - 115,200 bit/s
Range
approx. 15 m (according to EIA-232)
Galvanic isolation
AC
3,5 kV; 50 Hz; 1 min
Communication – Fibre Optic
Connector
rear, ST
Cable
multi-mode; 62,5/125 μm; 50/125 μm,
100/140 μm, 200 μm
Wavelength
820 nm
Transfer speed
1200 bit/s - 115,200 bit/s
Range
approx. 1700 m
Transmitter optical power
-15 dBm
Receiver sensitivity
-34 dBm
Allowed optical loss
≤ 6,8 dB (62,5 / 125 μm; 1700 m;
-15 dBm / -34 dBm)
Communication – EXT (for extended modules only)
Connector
rear, RJ45
Cable
attached to the external module
Transfer speed
not settable
Range
according to external module ordering
Galvanic isolation
AC
0,5 kV; 50 Hz; 1 min
Communication – USB
Connector
front, type A
Supported type
1.0, 2.0
Supported storage size
≤ 32 GB
Supported file system
FAT32
Transfer rate
≈ 1,2 Mbit/s
Bridgeable distance
< 6 m
Table 117 Technical characteristics of the device.
