Technical data
172 USER MANUAL FPC 200 - 3/2017
Mechanical characteristics
Dimension (W x H x D)
150 x 176 x 125 mm
Weight
2080 g
Material
Housing
Stainless steel
IP protection level
Front
IP54
Rear
IP40
Environment
Degree of pollution
IEC 60255-27
2
Maximum altitude above sea level
2000 m
Operation temperature range
-25 °C to +70 °C
Measuring & protection tolerances
Current
Accuracy - measurements
phase inputs
≤ ±0,5 % 

(0,1 

≤ I ≤ 4 

; 50 Hz; 25 °C)
≤ ±3 % 

(4 

≤ I ≤ 55 

; 50 Hz; 25 °C)


= 20 mA; 50 Hz; 25 °C
sensitive (earth) input
≤ ±0,2 % 

(0,001 

≤ I ≤ 2 

; 50 Hz; 25 °C)


= 0,5 mA; 50 Hz; 25 °C
Accuracy - protections
phase inputs
≤ ±3 % 

(0,1 

≤ I ≤ 4 

; 50 Hz; 25 °C)
≤ ±3 % 

(4 

≤ I ≤ 55 

; 50 Hz; 25 °C)
sensitive (earth) input
≤ ±3 % 

(0,001 

≤ I ≤ 2 

; 50 Hz; 25 °C)
Accuracy - harmonics amplitude
≤ ±0,2 % 

(0,01 

≤ I ≤ 0.5 

)
Temperature stability
Amplitude
≤ ±0,1 % 

/ 10 °C
Voltage
Accuracy
≤ ±0,1 % 

(1 V ≤ U ≤ 250 V; 50 Hz; 25 °C)
≤ ±0,5 % 

(250 V ≤ I ≤ 600 V; 50 Hz; 25 °C)


= 0,4 V; 50 Hz; 25 °C
Temperature stability
≤ ±0,25 % / 10 °C
Frequency
Accuracy - measurements
Current inputs
0,02 Hz (0,1 

≤ I ≤ 4 

; 50 Hz; 25 °C)
Voltage inputs
0,02 Hz (0,1 

≤ U ≤ 4 

; 50 Hz; 25 °C)
Current reference
0,02 Hz (20 Hz ≤ f ≤ 80 Hz; 

; 25 °C)
Voltage reference
0,02 Hz (20 Hz ≤ f ≤ 80 Hz; 

; 25 °C)
Accuracy - protections
Phase inputs
0,02 Hz (0,1 

≤ U ≤ 4 

; 50 Hz; 25 °C)
Temperature stability
≤ ±0,005Hz / 10 °C
Angles
Accuracy
Between currents
2 ° (0,1 

≤ I ≤ 1 

; 50 Hz; 25 °C)
4 ° (1 

≤ I ≤ 4 

; 50 Hz; 25 °C)
Between voltages
1 ° (0,1 

≤ I ≤ 2 

; 50 Hz; 25 °C)
Between current and phase voltage
2 ° (0,1 

≤ I ≤ 1 

; 50 Hz; 25 °C)
(0,1 

≤ I ≤ 2 

; 50 Hz; 25 °C)
4 ° (1 

≤ I ≤ 4 

; 50 Hz; 25 °C)
(0,1 

≤ I ≤ 2 

; 50 Hz; 25 °C)
Table 118 Technical characteristics of the device.
