Jacobsen HR 5111 Parts And Maintenance Manual

138
HR-5111
Item
Reference
Illustration
Part
Number
Description Serial Numbers/Notes
B1 See 3.1
N/S Battery
CB1 See 6.1
338601 10 Amp Circuit Breaker (Interlock)
CB2 See 6.1
338601 10 Amp Circuit Breaker (Instruments)
CB3 See 6.1
338601 10 Amp Circuit Breaker (Cruise, 4WD)
CB4 See 6.1
338558 30 Amp Circuit Breaker (Accessories)
CB5 See 6.1
338558 30 Amp Circuit Breaker (Lights)
CB6 See 21.1
361439 50 Amp Circuit Breaker (Main)
CB7 See 21.1
361439 50 Amp Circuit Breaker (Alternator)
D1
Not Shown 555846 Diode, 3 Amp (Water Temp-Test) Labled A
D2
Not Shown 555846 Diode, 3 Amp (Water Temp-Horn) Labled B
D3
Not Shown 555846 Diode, 3 Amp (Air Cleaner-Test) Labled C
D4
Not Shown 555846 Diode, 3 Amp (Return Filter-Test) Labled D
D5
Not Shown 555846 Diode, 3 Amp (Oil Temperature-Test) Labled E
D6
Not Shown 555846 Diode, 3 Amp (Oil Temperature-Horn) Labled F
D7
Not Shown 555846 Diode, 3 Amp (Charge Filter-Test) Labled G
D8
Not Shown 555846 Diode, 3 Amp (Cruise Control) Labled H
D9
Not Shown 555846 No Function Labled J
D10
Not Shown 555846 No Function Labled K
K1 See 43.1
131905 Glow Plug Solenoid
K2 See 43.1
365963 Accessory Relay Labled 6
K3 See 43.1
365963 Fuel Solenoid Relay Labled 4
K4 See 43.1
3003036 Seat Time Delay Relay
K5 See 43.1
3001307 Brake Relay Labled 1
K6 See 43.1
365963 Cruise Control Relay Labled 2
K7 See 43.1
365963 Horn Relay Labled 5
K8 See 43.1
365963 Right Wing Limit Switch Relay
K9 See 43.1
365963 Left Wing Limit Switch Relay
K10 See 56.1
5001354 Front Deck Valve Coil Included in Part No. 1002499
K11 See 56.1
5001354 Right Wing Deck Coil Included in Part No. 1002499
K12 See 56.1
5001354 Left Wing Deck Coil Included in Part No. 1002499
K13 See 52.1
556849 Differential Lock Coil Included in Part No. 1004555
K14 See 52.1
556849 4WD Coil Included in Part No. 1004555
K15 See 53.1
556849 4WD Reverse Coil Included in Part No. 1003025
K16 See 11.1
340783 Cruise Control Magnet
K17 See 23.1
338289 Fuel Solenoid
L1
Not Shown 555845 Right Turn Indicator Light
L2
Not Shown 555845 Glow Plug Active Light
L3
Not Shown 555845 Air Cleaner Service Light
L4
Not Shown 555845 Return Filter Service Light
L5
Not Shown 555845 Hydraulic Oil Temp Warning Light
L6
Not Shown 555845 Charge Filter Service Light
L7
Not Shown 555845 Low Charge Pressure Warning Light
L8
Not Shown 555845 Water Temp Warning Light
L9
Not Shown 555845 Low Engine Oil Pressure Warning Light
