Jacobsen HR 5111 Parts And Maintenance Manual

139
HR-5111
L10
Not Shown 555845 Left Turn Light
L11 See 43.1
555869 Tail Light
L12
Optional Head Light Included in Kit 69128
L13
Optional Head Light Included in Kit 69128
M1 See 21.1
556988 Starter Motor Included in Engine
R1 See 21.1
556996 Glow Plugs Included in Engiine
SW1 See 9.1
1001958 Ignition Switch
SW2 See 13.1
1000649 Parking Brake Switch
SW3 See 4.1
554390 Seat Switch
SW4 See 6.1
3001372 PTO Switch
SW5 See 9.1
365043 Glow Plug Switch
SW6 See 6.1
3001374 Wing Mower Switch
SW7 See 6.1
3001373 Front Mower Switch
SW8 See 17.1
366989 Right Wing Deck Limit Switch
SW9 See 17.1
366989 Left Wing Deck Limit Switch
SW10 See 15.1
3001079 Front Deck Limit Switch
SW11 See 19.1
364883 Air Cleaner Service Switch
SW12 See 27.1
365974 Return Filter Service Switch
SW13 See 28.1
367551 Hydraulic Oil Temperature Switch
SW14 See 27.1
556419 Charge Filter Service Switch
SW15 See 26.1
132380 Charge Pressure Switch
SW16 See 21.1
3001855 Water Temperature Switch
SW17 See 21.1
554018 Oil Pressure Switch Included in Engine
SW18
Optional 3001374 Light Switch Included in 69129 and Kit 69128
SW19 See 6.1
3001370 4WD Switch
SW20 See 6.1
162739 Horn / Warning Light Test Switch
SW21 See 12.1
1000649 Brake Pedal Switch
SW22 See 6.1
3001371 Cruise Control Switch
SW23 See 10.1
1000649 Reverse Sensing Switch
SW24
364882 Differential Lock Switch
U1 See 21.1
5000938 Alternator (Standard) Included in Engine
U2 See 43.1
5000917 Horn
U3 See 6.1
339027 Tachometer
U4 See 6.1
162721 Volt Meter
U5 See 6.1
162723 Hour Meter
U6 See 9.1
3005121 Temperature Gauge
U7 See 6.1
365943 Fuel Gauge
U8 See 25.1
163986 Fuel Sender
U9 See 22.1
163373 Engine Speed Sensor
U10 See 20.1
162722 Temperature Sender
U11 See 25.1
163574 Fuel Pump
Item
Reference
Illustration
Part
Number
Description Serial Numbers/Notes
