Compressor control and surveillance
Depending on the compressor type, the default settings and the min. and max. settings are as listed
here; default value [min., max.]:
Compressor
Motor rpm min. Motor rpm max.
SMC/HPC 500 [500,1000] 1500 [1100,1800]
HPX 500 [500,1000] 1800 [1100,1800]
CMO/HPO 700 [700,1000] 1800 [1100,1800]
The minimum compressor capacity for a typical 4-pole motor at 50 Hz running Speed mode will be:
Compressor type Standard motor Special motor
SMC/HPC 104 and HPX 704 47%
700 rpm
33%
500 rpm
SMC/HPC 106 and HPX 706 47%
700 rpm
33%
500 rpm
SMC/HPC 108 and HPX 708 17%
500 rpm
TSMC 108 11%
500 rpm
SMC/HPC 112 and HPX 712 17%
500 rpm
SMC/HPC 116 and HPX 716 8%
500 rpm
TSMC 116 6%
500 rpm
CMO/HPO 24 50%
900 rpm
39%
700 rpm
CMO/HPO 26 19%
700 rpm
CMO/HPO 28 19% 700 rpm
TCMO 28 13%
700 rpm
