124
POWERHEAD
SHIFT LINKAGE
SHIFT LINKAGE
Removal
Remove the lower engine covers as described in
REMOVAL on p. 128.
Remove the clip and drive pin from shift handle.
Remove the screw retaining the shift handle.
Remove the lockout rod.
Remove the choke lever and grommet.
Remove the pin, shift rod, and grommet.
Remove the screw and detent springs.
32338
32337
32336
32333
32344
32320
