148
MIDSECTION
TORQUE CHART
TORQUE CHART
* Back off nut 1/4 turn after torquing.
IMPORTANT: For fasteners not listed, refer to STANDARD TORQUE SPECIFICATIONS on p. 20.
Description 9.9/15 Lubricant
Upper Mount to Exhaust Housing
60 to 84 in. lbs.
(7 to 9 N·m)
Nut Lock
Upper Side Mount to Exhaust Housing Nut Lock
Upper Mount to Steering Bracket
18 to 20 ft. lbs.
(24 to 27 N·m)
Nut Lock
Lower Mount to Exhaust Housing Nut Lock
Lower Mount Bracket Screws
60 to 84 in. lbs.
(7 to 9 N·m)
Nut Lock
Steering Bracket to Pivot Shaft Screws
18 to 20 ft. lbs.
(24 to 27 N·m)
Screw Lock
Lower Side Mount Nuts
Gasket Sealing Com-
pound
Upper Side Mount Nuts
Gasket Sealing Com-
pound
Tilt Bolt Nut
60 to 84 in. lbs
(7 to 9 N·m)
Tilt Tube Nut *
50 to 54 ft. lbs.
(68 to 73 N·m)
Idle Relief Muffler Screws
48 to 60 in. lbs.
(5 to 7 N·m)
Nut Lock
