Johnson J10RSUR

171
GEARCASE
DISASSEMBLY
9
DISASSEMBLY
Remove gearcase. Refer to REMOVAL AND
INSTALLATION on p. 167.
Remove water pump and driveshaft from gear-
case. Refer to WATER PUMP on p. 169.
Remove the propeller shaft bearing housing
retaining screws. Using Gearcase Bearing Hous-
ing Puller, P/N 386631, and a propeller nut,
remove the propeller shaft bearing housing.
Remove the propeller shaft, with thrust washers,
and reverse gear components. If forward thrust
washer is not on propeller shaft, check for it in the
relieved area of the forward gear. Use a magnetic
tool to locate and remove the two shifter detent
balls and one detent spring from the gearcase.
Remove shift lever pivot pin from gearcase. Dis-
card the O-ring.
Unscrew the shift rod and remove it from the gear-
case.
1. Water pump assembly
2. Driveshaft
32539
1. Gearcase Bearing Housing Puller
2. Propeller nut
32534
2
1
1
2
44107
1. Shifter lever pivot pin 32536
32575
1
