174
GEARCASE
BEARING AND SEAL REMOVAL
Remove and discard the O-ring(s) and washer
from the bushing.
Prop Shaft Bearing Housing Seals
and O-ring
Remove and discard the propeller shaft bearing
housing O-ring.
Using Puller Bridge, P/N 432127, and Small Puller
Jaws, P/N 432131, remove seal(s). Discard
seal(s).
Prop Shaft Bearing Housing
Bearings
Using Bearing Remover, P/N 319880, and a mal-
let, remove the smaller propeller shaft bearing
located in the aft end of the bearing housing. Dis-
card the bearing.
1. Adapter
2. Shift rod bushing
3. Remover tool, P/N 327693
DRC1505
TYPICAL
1. O-ring
32547
1
23
1
1. Small puller jaws 32555
1. Bearing remover 32554
1
1
