190
MANUAL STARTER
INSTALLATION
INSTALLATION
Position starter on engine. Connect starter lockout
link to cam. Turn cam screw IN carefully until
screw head contacts cam. Do not overtighten.
Install starter screws. Tighten screws 60 to 84 in.
lbs. (7 to 9 N·m).
Check operation of starter and starter lockout.
Starter should crank outboard in NEUTRAL gear.
Starter MUST NOT crank outboard in FOR-
WARD or REVERSE gear.
1. Lockout link 33746
1
1. Starter screws 32312
1
1
