154
MIDSECTION
STEERING HANDLE
Thread the throttle cable anchor onto the cable
housing until anchor is flush with end of threads.
Thread the cable end connector on the cable until
seated.
Position the throttle cable connector into throttle
lever and insert pin. Position throttle cable anchor
on powerhead and secure with shoulder screw
and washer.
Hook cable retainer around throttle cable and
install air silencer.
Install manual starter and lower motor covers.
To adjust the throttle cable, refer to SYNCHRONI-
ZATION AND LINKAGE ADJUSTMENTS on
p. 59.
1. Throttle cable anchor
2. Threads
3. Cable end
DR4947
35281
1
2
3
35300
