Section 2 Installation
28
MAX 9.8
8-CORES
COMPOSITE CABLE
10 m : CFQ6531-10
15 m : CFQ6531-15
20 m : CFQ6531-20
Installing the Scanner Unit
Connecting the Scanner Unit Cable
Connect the scanner unit cable as follows.
Figure 2-3
CAUTION
Be careful not to injure your finger or hand by the waterproof cap mounting
groove when installing the Display connector.
Unit : mm
