Juniper EX9214 Hardware Guide

• To check the status of the Switch Fabrics, issue the show chassis environment cb command. The output is
similar to the following:
user@switch> show chassis environment cb
CB 0 status:
State Online Master
Temperature 30 degrees C / 86 degrees F
Power 1
1.0 V 1005 mV
1.2 V 1218 mV
1.5 V 1475 mV
1.8 V 1830 mV
2.5 V 2520 mV
3.3 V 3345 mV
5.0 V 5053 mV
5.0 V RE 4962 mV
12.0 V 12220 mV
12.0 V RE 12123 mV
Power 2
4.6 V bias MidPlane 4840 mV
11.3 V bias PEM 11176 mV
11.3 V bias FPD 11292 mV
11.3 V bias POE 0 11272 mV
11.3 V bias POE 1 11311 mV
Bus Revision 64
FPGA Revision 13
PMBus Expected Measured Measured Calculated
device voltage voltage current power
XF ASIC A 1000 mV 998 mV 13609 mA 13581 mW
XF ASIC B 1000 mV 1000 mV 12390 mA 12390 mW
CB 1 status:
State Online Standby
Temperature 30 degrees C / 86 degrees F
Power 1
1.0 V 1002 mV
1.2 V 1214 mV
1.5 V 1472 mV
1.8 V 1804 mV
2.5 V 2520 mV
3.3 V 3325 mV
5.0 V 5053 mV
5.0 V RE 4969 mV
244
