below the line card and SF module slots. You can use cable strips or other es to gently secure the
cables to the cable management bracket.
Figure 14: Cable Management Bracket
CAUTION: You can pull the cable management bracket up and outward to lock it into
the maintenance posion, so you can access the lower fan tray and the air lter.
SEE ALSO
Installing the Cable Management Bracket in an EX9214 Switch | 281
EX9214 Cooling System
IN THIS SECTION
Fan Tray | 41
Airow Direcon in the EX9214 Switch Chassis | 42
The cooling system in an EX9214 switch consists of two eld-replacable unit fan trays and an air lter
that provide front-to-rear chassis cooling.
40
