Table 5: Physical Specicaons of the EX9214 Switch Chassis
(Connued)
Descripon Weight Height Width Depth
Switch Fabric
module (SF
module)
9.6 lb (4.4 kg) (with
Roung Engine
installed)
1.25 in. (3.2 cm) 17 in. (43.2 cm) 22 in. (55.9 cm)
EX9200-SF3
Switch Fabric
module
13.6 lb (6.2 kg) 1.2 in. (3.05 cm) 15.7 in. (39.87 cm) 21.2 in. (53.85 cm)
Fan tray 13 lb (5.9 kg) 1.4 in. (3.6 cm) 16.9 in. (43 cm) 20.6 in. (52.3 cm)
Air lter 1.0 lb (0.5 kg) 0.43 in. (1.1 cm) 16.7 in. (42.4 cm) 19.7 in. (50 cm)
Cable
management
bracket
4.1 lb (1.9 kg) 6.7 in. (17 cm) 18.9 in. (48 cm) 5.5 in. (14 cm)
AC power supply 11.9 lb (5.4 kg) 1.75 in. (4.5 cm) 14.5 in. (36.8 cm) 6.85 in. (17.4 cm)
DC power supply 15.8 lb (7.2 kg) 1.75 in. (4.4 cm) 14.5 in. (36.8 cm) 9.05 in. (23 cm)
EX9200-2C-8XS
line card
19.4 lb (8.8 kg) 1.25 in. (3.2 cm) 17 in. (43.2 cm) 22 in. (55.9 cm)
EX9200-4QS line
card
16.8 lb (7.6 kg) 1.25 in. (3.2 cm) 17 in. (43.2 cm) 22 in. (55.9 cm)
EX9200-6QS line
card
21 lb (9.25 kg) 1.25 in. (3.2 cm) 17 in. (43.2 cm) 22 in. (55.9 cm)
EX9200-MPC
line card
15.96 lb (7.3 kg) 1.25 in. (3.2 cm) 17 in. (43.2 cm) 22 in. (55.9 cm)
