About the E-Plex Advanced AC
E-Plex Advanced ACS User’s Guide
PKG 3114 0106 1–3
Prox Card Only (E-Plex 5700 only)
Only the presentation of a valid Prox Card is required to access the lock.
PIN and Prox Card (E-Plex 5700 only)
The entry of a valid PIN followed by the presentation of a valid associated Prox Card is
required to access the lock. Access via PIN and Prox Card is identified as “dual credential”
access.
Prox Cards and Prox Card Reader/Enroller (E-Plex 5700 Only)
The E-Plex 5700 lock supports HID Prox Card access as a method of lock entry for users.
The Master Operator can enroll Prox Cards for users at the PC via the pcProx™
Card
Reader/Enroller, or through the manual Batch Enroll method.
Note 1: The E-Plex 5700 lock supports only HID-supported Prox Cards with Wiegand bit
formats from the standard 26 bits up to 84 bits.
Note 2: The Prox Card Reader/Enroller is recommended but not required if only the
standard 26-bit Wiegand format Prox Cards are used in the system.
PC and E-Plex Advanced ACS Software
The E-Plex Advanced ACS software is installed on the PC and allows you to manage your
door locks and the associated user data from the PC. It also offers audit and reporting
capabilities.
M-Unit and E-Plex Advanced ACS M-Unit Software
The E-Plex Advanced ACS M-Unit software is installed on the M-Unit and allows for
programming (uploading) and auditing (downloading) of data to and from the lock. It also
allows for the download of User Table and lock Audit data from the lock to use for reporting
purposes at the PC.
System Definitions
This section contains system definitions for the following items.
• PC System Operator Classifications
• PINs
• Door Groups
• Access Schedules
• Holidays/Vacations
• Lock User Personnel Classifications
