Kaba E-Plex 5200 User Manual

Operating the E-Plex Lock at its Keypad
4–4 PKG 3114 0106
E-Plex Advanced ACS User’s Guide
The lock is now “activated” and can be programmed using the M-Unit (Maintenance Unit)
Palm PDA. For
Programming and Auditing Locks using the M-Unit, refer to Chapter 5.
Default Values of the E-Plex 5200 and E-Plex 5700 Lock
Programmable Parameters
Parameters Factory Default Values
Date (MM/DD/YY) 01/01/00
Time (HH:MM) 00:00
Lock state Un-programmed
Lock function Entry
Manual Passage Mode open time limit Four hours
Passage Mode Disabled
Lockout Mode Disabled
Unlock time Two seconds
Buzzer volume control Low
Tamper shutdown time 30 seconds
Tamper attempt count Four attempts
Access code length Four digits
Master PIN 12345678 (Eight digits)
M-Unit user’s status Disabled
Remote unlock Disabled
Configuring the Lock Functions
Before putting the lock in service, you must first program the Lock Function when still in
Factory Mode. The default lock function for any lock from the factory is “Entry” lock function,
which is the same as a Cylindrical lock without a privacy thumbturn, a Mortise lock without a
deadbolt, or an Exit Trim lock. The command codes involved here are 011# and 013#. Refer
to the separate “E-Plex 5X00 Mortise and Thumbturn Addendum” sheet for detailed
instructions.
Initial Programming of the Lock
Once the required lock function is set, the lock must be programmed before daily use. This
section provides information about the initial programming of the lock, including:
•
Entering Pushbutton Programming Mode
•
Modifying the Master User PIN (Command 000#)
•
Additional Pushbutton Keypad Commands
•
Resetting the Lock
•
Summary of Pushbutton Programming Commands
•
Visual Feedback Message Definitions
