17.1.2Parameterlist
ID Index Name/Setting Unit Description
97  PARA_
DataSetLdCfg
 DataSetLoaderConfiguration
 0 Opt  Configurationoptions
 
OFF (0)
 Functionnotactive
 
ON(1)
 Activatefunction
 1
FS:
 Functionselector
  0=OFF  NodatasetIDisdetermined.
  1=TERM  Determinationviadigitalinputs(MPRO_INPUT_STATE
&PARA_DataSetLdCfg[1])
  2=PARA  ThedatasetIDisdeterminedfromaselectable
parameter.Thevalueoftheparameter(Para_
ID/ParaSubID)isusedtogeneratethedatasetID.
 2 Mask  Bitmask
 3 ActID  CurrentlyselecteddatasetID
 4 Para_ID  ParameterindexforgeneratingthedatasetID(if
FS=PARA)
 5 Para_SubID  ParametersubindexforgeneratingthedatasetID(if
FS=PARA)
 6 Para_Scale  Theparametervalueisscaled(multiplication)forthe
generationofthedatasetIDusingthevalueindicated.
 7 Para_Offset  ParameteroffsetforgeneratingthedatasetID
98  PARA_
DataSetLdID
 
 0-99 PARA_
DataSetLdID
 ListofthepossibledatasetIDs
99  PARA_
DataSetLdVal
 
 0-99 PARA_
DataSetLdVal
 Associatedcharacterstringswhichdescribe
parametersandvalueswhicharetobechanged
Table 16.5: Parameter “Reloading individual parameters”
Activation
The function is activated by the setting of the parameter P 97 - PARA_DataSetLdCfg
[0] Opt = 1.
Determining the data set ID
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
478
17 Enhanced/additional functions
The parameter P 97 - PARA_DataSetLdCfg[1] FS is the function selector and
specifies which source is used for determining the data set ID.
The parameter P 97 - PARA_DataSetLdCfg[2] (= PARA_DataSetLd_Mask) functions
in this case as the bitmask for selecting (e.g. the desired digital inputs).
off(0) ManualswitchoverviaActID
1 Switchoverviadigitalinputs
2 Switchoverviaseparateparameter
The currently determined data set ID is displayed in parameter P 97 - PARA_
DataSetLdCfg[3] (= ActID).
Manual allocation of the data set ID
If parameter P 97 - PARA_DataSetLd_FS = OFF(0), then the data set ID can be
allocated “manually.”
Every imaginable data set ID should be entered in parameter P 98 - PARA_
DataSetLdID[x] at least once under any subindex desired.
Automatic data set ID determination
Parameter P 97 = Para(2) allows switching between the data set IDs via any
parameter desired (for example, a fieldbus parameter). To do so, the parameter must
be entered in P 97.4 and the associated subindex in P 97.5. The value of the
parameter entered is overwritten in P 97.3.
Using parameter P 97 - PARA_DataSetLd_FS = PARA(2), the data set ID is
determined automatically from the current value of the parameter specified by P 97 -
PARA_DataSetLdCfg[4] and P 97 - PARA_DataSetLdCfg[5] and is entered in P 97
- PARA_DataSetLd [3] = ActId.
