Load Edge Series
100 Parallel Operations
Fig. 9-1-2 Connection between slaves (BOOSTER connection cables)
Use rear input terminals when in parallel operation. Never connect any devices to the
front panel terminals.
Use as short as possible cable and appropriate size for the current.
To minimize influence, place the load cable and BOOSTER connection cable as far as
possible.
C
A
U
T
I
O
N
