Load Edge Series
108 Parallel Operations
9.2 Multi-Channel Synchronized operation
The Multi-channel Synchronized operation can test or evaluate multiple outputs DC power
supply simultaneously. (Synchronized)
This mode provide synchronized load ON or OFF operation.
In this operation, ELA, ELB or ELC series electronic load can be connected regard less to the
input voltage rating.
In dynamic mode, reference clock signal is fed from the master unit to slave units for
synchronization.
In dynamic operation, Single mode is possible independently.
There is no BOOSTER function selection on slave unit.
When in [MULTI] setting, [MASTER] selection cannot be seen and when in [MASTER] setting,
[MULTI] is not seen.
When set DYNAMIC ON/OFF of each unit, the phase will shift.
When to synchronize the starting timing, set LOAD OFF ON of the MASTER unit.
The ALARM is not synchronized. Hence the unit being generated ALARM will turn off the
LOAD but LOAD LED is in ON.
In DYNAMIC mode, the time setting of the SLAVE units are in accordance to the MASTER
unit.
--- Timing range ---
0.001ms =< Time 1 =< 20ms
0.010ms =< Time 2 =< 200ms
0.1ms =< Time 3 =< 2S
1ms =< Time 4 =< 20S
10ms =< Time 5 =< 200S
100ms =< Time 6 =< 2000S
