Load Edge Series

76 Alarms

7.2 Over voltage alarm

When the load volt exceeds the tolerance value, this alarm operates. This protection will

be activated when applied 104% (typ) of rated voltage.

Model

Range HIGH

Range LOW

ELZ-175

31.2V

4.16V

Table 7-2-1 Threshold voltage for OVP.

Fig. 7-2-1 Display of over voltage alarm

・ This is alarm only and the load section won‟t be protected by this alarm.

・ When an alarm is issued, if you find a phenomenon of a trouble like abnormal

smell, sound, please stop using immediately, and ask us for repair.
