Load Edge Series

Operations for Load Mode 47

5.3 Response Rate

You can change the response speed (slew rate) of both rising and falling time that is effective

when load is ON/OFF and load condition changes. The response speed depends on the current

range selected then. Load response speed of both rising and falling time is identically setup.

The load modes in which you can change the response speed are as follows:

1. CC mode

Settable load response range is as follows:

Table 5-3-1 Slew rate at CC mode

2. EXT. mode

Settable load response range is as follows:

Table 5-3-2 Slew rate at EXT mode

3. CV mode

Settable load response are Fast (300μs)/ Slow(10ms) (loop gain setting)

Notes: CV mode

In CV mode, setting value is any of Fast or Slow only.

This value can be fixed regardless of voltage range selected.

Oscillation.

If oscillation happened due to the combined condition of response speed of this product

and the target device connected, please adjust to decrease the loop gain value to slow

response speed of this product to stop the oscillation. The proper value depends on

target devices.

Model

High range

Low range

ELZ-175

0.25A～25A/μs

0.025A～2.5A/μs
