KEISOKU GIKEN LOAD EDGE Series User Manual

Load Edge Series
Alarms 79
7.5 Stop an alarm
Alarm can be stopped by pressing CE key.
Note: Make sure to remove the cause of the alarm before stopping the alarm.
Fig. 7-5-1 CE key
7.6 Instant power limited status
Maximum power is limited when 175W (Typ) < Pin or according to the Peak Power Limit
condition.
For the Peak Power Limit Condition, refer to → “ 10.6 Operation Area ”
Fig. 7-6-1 Display status when the power limited
Set the remote sensing selector switch at “EXT” position when remote
sensing is used.
Set it at “INT” position otherwise.
Contrary to this may cause measurement error or malfunction of setting
and power limit.
For detailed about the connection refer to →“ 2.2 Cable Connections”
7
4
1
0 .
2
5
8 9
6
3
CE ENT
ON /OFF
F1
F2
F3
MENU
W
A
R
N
I
N
G
L
i
m
i
t
S
t
a
t
u
s
