Load Edge Series
Operations for Load Mode 41
4.6.3. After Selecting, If you want to finish this mode, Push MENU Key.
4.6.4. If you turn BIAS Unit on during load ON state, a warning appears.
図 4-6-3 Bias Unit warning
4.6.5. In this case
Push MENU Key or CE Key
Push MENU Key again and BIAS mode is closed.
Push LOAD ON/OFF Key and loading is stopped.
As mentioned above,pleas retry to turn BIAS Unit on.
4.6.6. In case of turning BIAS Unit ON, inverse voltage (0.66 V) is generated between
ELZ-175‟s load terminal.
4.6.7. In case of turning BIAS Unit OFF, BIAS Unit has short state.
To Next Page
