MEMory:TABLe:SELect <"name">
MEMory:TABLe:SELect?
Creates a new table in volatile memory to be programmed with a list of voltage and current points.
Table names cannot be longer than 12 alphanumeric characters and must start with an alpha
character. Table names are converted to upper case. If you send this command without specifying a
table name, it will de-select the selected table.
This command is also used to select an existing table in non-volatile memory to be copied into volatile
memory for appending additional voltage and current points. A selected table can be copied into non-
volatile memory using MEMory:COPY:TABLe.
Parameter Typical Return
<"name"> the table name <"curve1">
Selects or creates the table named curve1:MEM:TABL:SEL "curve1"
Queries the selected table: MEM:TABL?
l
To activate a table in Table mode, use [SOURce:]CURRent:TABLe:NAME.
MEMory:TABLe:VOLTage[:MAGNitude] <voltage>{,<voltage>}
MEMory:TABLe:VOLTage[:MAGNitude]?
Programs a list of voltage points for a new table. A table must have at least 3 points. You may, but are
not required to send all the table points in one command. Repeatedly sending this command will
append additional points to the end of the table, up to a maximum of 4000 points. A maximum of 30
tables can be stored in volatile memory.
The query returns the voltage points in the active table.
Parameter Typical Return
<voltage> 0 to the rated voltage. *RST 0
Values must be in equal or ascending order, or an error will occur.
<+5.400000E+01,+5.600000E+01,+5.700000E+01,
+5.800000E+01,+5.900000E+01>
Programs five data points in a new table: MEM:TABL:VOLT 54,56,57,58,59
l
To copy a table from volatile to non-volatile memory, use MEMory:TABLe:SELect and
MEMory:COPY:TABLe.
l
Querying values from a table where no values have been set will return NAN (9.91E37).
MEMory:TABLe:VOLTage[:MAGNitude] :POINts?
The query returns the number of voltage points in the active table.
Parameter Typical Return
(none) <# of points>
Return the number of points in the active table: MEM:TABL:VOLT:POIN?
Keysight MP4300 Series Operating and Service Guide 127
5 SCPI Programming Reference
