E4360A Compatibility
This section describes the primary features of the Keysight MP4360A Modular SAS Power System and
how they compare with the primary features of the Keysight E4360A Modular Solar Array Simulator.
Differences in General
Items MP4360A Modular Power System E4360A Modular SAS
Description: MP4301A 6000 W Modular SAS; 200-208 VAC
MP4302A 6000 W Modular SAS; 380-480 VAC
E4360A 1200 W Modular SAS
Power: Up to 6000 W with six modules installed Up to 1200 W with two modules installed
Dimensions: 2 U
Height 88.1mm, Width 428.9mm, Depth 765.6 mm
2 U
Height 88.9mm, Width 432.5mm, Depth 608.5 mm
Rack
mounting:
Standard support rails and ears Custom rack mount kit
Weight: 29.5 kg with six modules installed 18.6 kg with two modules installed
AC input: 200-208 VAC nominal, 3-phase or
380-480 VAC nominal, 3-phase
100, 120, 220, 240 VAC nominal
Universal input; no switch setting
At 100/120 VAC nominal, max current is derated by half
Power cord: Supplied by customer Supplied with mainframe
Power
dissipation:
Directs excess power at the output back to the AC mains Not available
Interfaces: GPIB (optional), LAN, USB, USB-C, built-in Web server GPIB, LAN, USB, built-in Web server
Module
installation:
Modules install through the back of the mainframe
After installation, the lockout bar must be installed
Modules install through the top of the mainframe after first
removing the blower cover
Front panel
controls:
Minimal font panel buttons
High-resolution display with built-in touch controls
Individual keys for main functions
Extensive menu controls
Output
ratings:
6 outputs; up to 1 kW per output
10 A or 8 A (module dependent)
2 outputs; up to 600 W per output
8.5 A or 5 A (module dependent)
