Keysight MP4300 Series User Manual

HCOPy Subsystem
HCOPy commands return the display image.
HCOPy:SDUMp:DATA? [JPG|PNG]
Returns an image of the front panel display. The format may be specified by the optional parameter. If
no format is specified, the format is determined by HCOPy:SDUMp:DATA:FORMat.
The response is a SCPI 488.2 definite length binary block of the form: #<nonzero digit><digits><8 bit
data-bytes> where:
<nonzero digit> specifies the number of digits to follow,
<digits> specify the number of 8 bit data bytes to follow, and
<8 bit data bytes> contain the data to be transferred.
Parameter Typical Return
[JPG|PNG] <Block>
Returns the image in PNG format: HCOP:SDUM:DATA? PNG
HCOPy:SDUMp:DATA:FORMat JPG|PNG
HCOPy:SDUMp:DATA:FORMat?
Specifies the format for front panel images returned.
Parameter Typical Return
BMP|JPG|PNG, *RST PNG JPG, or PNG
Specify JPG as the image format: HCOP:SDUM:DATA:FORM JPG
Keysight MP4300 Series Operating and Service Guide 117
5 SCPI Programming Reference
