Keysight MP4300 Series User Manual

Specifications and Characteristics
Power Module Specifications and Characteristics
Mainframe Characteristics
Power Module Output Quadrants
Outline Diagram
Unless otherwise noted, specifications are warranted over the ambient temperature
range of 0 to 40°C after a 30-minute warm-up period. Specifications apply at the
output terminals, with the sense terminals connected to the output terminals (local
sensing).
Power Module Specifications and Characteristics
Specifications
Parameter Keysight MP4361A Keysight MP4362A
Output Ratings in Fixed mode
Voltage source:
Current source:
Maximum Power:
0 to 160 V
0 to 10 A
1000 W
0 to 130 V
0 to 8 A
1000 W
Output Ratings in SAS and Table mode
Maximum Voc and Vmp:
Maximum Isc and Imp:
Maximum Power:
160 V
10 A
1000 W
130 V
8 A
1000 W
Current sink capability
Fixed mode:
SAS/Table mode:
0 to -10 A
0 to -0.5 A
0 to -0.5 A
0 to -0.5 A
Output ripple & noise
CV peak-to-peak:
1
CV rms:
2
500 mV
50 mV
500 mV
50 mV
Programming accuracy
3
Voltage:
Current:
0.05% + 25 mV
0.1% + 7 mA
0.075% + 25 mV
0.2% + 10 mA
Measurement accuracy
3
Voltage:
Current:
0.05% + 25 mV
0.1% + 7 mA
0.08% + 20 mV
0.2% + 25 mA
1
From 20 Hz to 20 MHz with 10 ohms in parallel with ≥100nF, or either terminal grounded
2
From 20 Hz to 10 MHz with 10 ohms in parallel with ≥100nF, terminals ungrounded, or either terminal grounded
3
@ 23°C ±5°C ≥
Keysight MP4300 Series Operating and Service Guide 29
1 Quick Reference

Keysight MP4300 Series Specifications
