Characteristics
Parameter Keysight MP4361A Keysight MP4362A
Programming range & resolution
Voltage:
Current:
Overvoltage:
Overcurrent:
0 - 163.2 V; 1.8 mV
0 -10.2 A; 0.12 mA
0 - 172.5 V; 1.8 mV
0 -12.5 A; 0.12 mA
0 - 132.6 V; 1.8 mV
0 - 8.2 A; 0.12 mA
0 - 142.5 V; 1.8 mV
0 -10 A; 0.127 mA
Programming accuracy
Overvoltageprotection:
Overcurrent limit/protection:
0.05% + 25 mV
0.1% + 7 mA
0.075% + 25 mV
0.2% + 10 mA
Output settling time:
1
Voltage:
Current:
35 ms
< 12.5 μs
35 ms
< 12.5 μs
Temperature Coefficients - output change per °C
Voltage:
Current:
0.01% + 1.5 mV
0.01% + 500 μA
0.01% + 1.5 mV
0.01% + 500 μA
Programming rise/fall time
2
Voltage:
Current:
< 8 ms
10 μs
< 8 ms
10 μs
Maximum shunt switching frequency: 20 kHz 20 kHz
Maximum MPPT tracking frequency: 200 Hz 200 Hz
SAS curve and table resolution: 1024 points 1024 points
Output capacitance: 80 nF 80 nF
Minimum impedance (Δ V/Δ I) - in SAS mode: 0.25 Ω 0.25 Ω
Maximum capacitive load:
3
2000 μF 2000 μF
Maximum lead inductance:
3
50 μH 50 μH
Output current noise
4
CC peak-to-peak:
CC rms:
48 mA
6 mA
48 mA
6 mA
Remote sense capability
Fixed mode:
SAS/Table mode:
up to 2 V total
up to 2 V + (Voc - Vmp)
up to 2 V total
up to 2 V + (Voc - Vmp)
Load
5
& Line
6
regulation
CV:
CC:
4 mV
1 mA
4 mV
1 mA
1
Output recovery to within 1.5 A of an operating point on the I-V curve (V < 90% of VMP) after switching from a short circuit to a fixed load
2
Time for output to change from 90% to 10% or 10% to 90% of its total excursion
3
Simulator, Table, and Fixed Modes
4
From 20 Hz to 20 MHz with 10 ohms in parallel with ≥100nF, or either terminal grounded
5
Change in output voltage or current for any load change within ratings
6
Change in output voltage or current for any line voltage change within ratings
