Figure 3-21. ARIES NETLink Set Menu Functions (Cont’d - Fig. 3 of 18)
3. SET
3. SLC Devices
Cont’d
*
2. Configuration
2. Photoelectric
1. Alarm
1. Fixed Settings
Set Detector Sensitivity
ENTER SLC LOOP NUMBER (1-8)_
SLC Devices From *__ to ___
(1-255)
Set Detector Sensitivity
1: Open Area 2: In Duct 3: DH-2000 *
Set Detector Sensitivity
Pre-Alarm Level *._
(0.2-3.4) %/ft.
Set Detector Sensitivity
Alarm Level *._
(0.5-3.5) %/ft.
2. Day/Night Settings
Set Detector Sensitivity
ENTER SLC LOOP NUMBER (1-8)_
SLC Devices From *__ to ___
(1-255)
Set Detector Sensitivity
1: Open Area 2: In Duct 3: DH-2000 *
Set Detector Sensitivity
Pre-Alarm Level *._
(0.2-3.4) %/ft.
Set Detector Sensitivity
Day Alarm Level *._
(0.5-3.4) %/ft.
Set Detector Sensitivity
Night Alarm Level *._
(0.5-3.4) %/ft.
2. Supervisory
Set Detector Sensitivity
ENTER SLC LOOP NUMBER (1-8)_
SLC Devices From *__ to ___
(1-255)
Set Detector Sensitivity
1: Open Area 2: In Duct/DH-2000 *
1. Fixed Settings
Set Detector Sensitivity
Alarm Level *._
(0.5-3.5) %/ft.
Set Detector Sensitivity
Day Alarm Level *._
(0.5-3.5 %/ft.
2. Day/Night Settings
Set Detector Sensitivity
Night Alarm Level *._
(0.5-3.4) %/ft.
3. Thermal
Set Detector Sensitivity
1: 50-ft. *
Set Detector Sensitivity
2: 70 ft. *
Set Detector Sensitivity
SLC MODULE NUMBER (1-8)_
SLC Devices From *__ to ___
(1-255)
Set Detector Sensitivity
Pre-Alarm Level *._
(80-135)
Set Detector Sensitivity
Alarm Level *._
(135-155)
Set Detector Sensitivity
Pre-Alarm Level *._
(80-135)
Set Detector Sensitivity
Alarm Level *._
(135-145)
*=
Level -2 (Installer) Password required .
