Kidde Fire Systems ARIES NETLink

Configuration and Programming
P/N 06-237058-001 3-33 February 2012
Figure 3-27. ARIES NETLink Set Menu Functions (Cont’d - Fig. 9 of 18)
3. SET
5. Globals
1. Global Acknowledge
Cont’d
*
3. Alarm Verify Timer
4. PAS Timer
5. Nightly Test Time
Set Nightly SLC Test Time (02:00)
Nightly Test Time *__ to ___
 (24 Hour Clock)
Positive Alarm Sequence Timer (000 Sec)
Investigation Period *_ (000- 180 Sec)

Global Acknowledge of TBL/Sup (Disabled)
1:Enable 2:Disable *

Alarm Verify Timer (060 Sec)
Verification Period *_ (060-180 Sec)

6. OUTPUTS/BACKPLANE
*
1: ON BOARD
1:NAC
*= Level -2 (Installer) Password required .
2. Global Alarm Ack
Global Alarm Acknowledge (Disabled)
1:Enable 2:Disable *

+= Not included in first release
1:RNAC
2:R-NAC
3:RELAY
ONBOARD CONFIGURATION
PRESS '0' TO EDIT THE PARAMETER
PRESS ENTER TO SELECT THE VALUE
BACKSPACE TO EXIT THE CONFIG
ENTER CIRCUIT NUMBER (1/2)
ON BOARD NAC #
CURRENT VALUE
OWNER LOCATION
ON BOARD NAC #
OWNER LOCATION
*____________________________
PRESS ‘0’ TO CHANGE SETTING
PRESS ENTER TO VIEW NEXT SETTING
ON BOARD NAC #
USE SCROLL FOR OPTIONS, ENTER TO SELECT
END OF CONFIGURATION, SAVE?
YES
SAME AS NACS above
except header is
“ONBOARD R-NAC #”
SAME AS NACS above
except header is
“ONBOARD RELAY #”
and there are 3 circuit
numbers (1/2/3)
2. BACKPLANE CONFIG
2:RELAY
3:CITY TIE
4:PMU/BATTERY
5:DACT+
After final parameter, the following appears
3. LEARN BACKPLANE
4. DEREGISTER MODULE
Deregister Backplane Modules
Valid Slot Numbers are 01 to 24 and
34 to 36 for PMUs 2 through 4
Please Enter Slot Number(s) *_ to __

34
35
36
37
38
39
40
