Kidde Fire Systems ARIES NETLink

Configuration and Programming
February 2012 3-44 P/N 06-237058-001
Figure 3-36. ARIES NETLink Set Menu Functions (Fig. 18 of 18)
Options for Softkey Assignment
NONE
ISOLATION MACRO
WALK TEST
SLC DEVICE TEST
FIND GROUND FAULT
BATTERY TEST
CALL FOR SERVICE
SLC LINE VOLTAGE
SLC LINE RESISTANCE
SOFTKEY #
SOFTKEY ASSIGNMENT: ISOLATION MACRO
ENTER ISOLATION MACRO NUMBER: * (1-4) 
SOFTKEY #
ASSIGNED TO ISOLATION MACRO Number
SOFTKEY #
SOFTKEY ASSIGNMENT:WALK TEST
ENTER SLC LOOP NUMBER(1-8): * 
SOFTKEY #
SOFTKEY ASSIGNMENT: WALK TEST
ENTER SLC LOOP NUMBER(1-8): 1
SLC DEVICES FROM *__ TO ___ (1-255) 
SOFTKEY #
ASSIGNED TO NONE
If ‘Isolation Macro’ selected
If ‘Walk Test’ selected
SOFTKEY #
SOFTKEY ASSIGNMENT:SLC DEVICE TEST
ENTER SLC LOOP NUMBER(1-8): * 
SOFTKEY #
SOFTKEY ASSIGNMENT: SLC DEVICE TEST
ENTER SLC LOOP NUMBER(1-8): 1
SLC DEVICES FROM *__ TO ___ (1-255) 
SOFTKEY #
ASSIGNED TO SLC DEVICE TEST
SOFTKEY #
SOFTKEY ASSIGNMENT:SLC LINE RESISTANCE
ENTER SLC LOOP NUMBER(0-8): * 
SOFTKEY #
ASSIGNED TO SLC LINE RESISTANCE
If ‘SLC Device Test’ selected
If ‘SLC Line Resistance’ selected
SOFTKEY #
ASSIGNED TO BATTERY TEST
SOFTKEY #
ASSIGNED TO FIND GROUND FAULT
SOFTKEY #
ASSIGNED TO CALL FOR SERVICE
SOFTKEY #
SOFTKEY ASSIGNMENT:SLC LINE VOLTAGE
ENTER SLC LOOP NUMBER(1-8): * 
SOFTKEY #
SOFTKEY ASSIGNMENT: SLC LINE VOLTAGE
ENTER SLC LOOP NUMBER(1-8): 1
SLC DEVICES FROM *__ TO ___ (1-255) 
SOFTKEY #
ASSIGNED TO SLC LINE VOLTAGE
If ‘SLC Line Voltage’ selected
If ‘Call for Service’ selected
If ‘Battery Test’ selected
If ‘Find Ground Fault’ selected
SOFTKEY #
ASSIGNED TO WALK TEST
If ‘None’ selected
