Networking
February 2012 5-22 P/N 06-237058-001
Use the following procedure to isolate a networked control unit:
1. Press the 0 Key on the keypad of the control unit being used to do the isolation. The display will
show this message:
Figure 5-26. Password Prompt
2. Enter the Level-2 Password and then press the <Enter> Key. The network-node prompt will
appear as follows:
Figure 5-27. Network Node Prompt
3. Select the local node by pressing the <Enter> Key, or enter a remote node number then press
the <Enter> Key. The top-level menu selections will be displayed.
Figure 5-28. Top-Level Menu Selections
4. Press the 1 Key to select the ISOLATE sub-menu
Figure 5-29. Isolate Sub-Menu
5. Select NETWORK and press <Enter>
Figure 5-30. Additional Isolate Menu Options
6. Select 1 to Isolate the local node from the Network or 2 to Isolate a remote node on the Network.
If REMOTE NODE is selected, a prompt for the node number is displayed:
Figure 5-31. Isolate/De-Isolate Nodes
7. Press the 1 key to select the local node or enter the remote node number and press <Enter>.
The following options appear:
Figure 5-32. Isolate Node Selection
PLEASE ENTER PASSWORD
****
PRESS ENTER TO SELECT THE LOCAL NODE
OR ENTER NETWORK NODE NO. (1 - 64)*
1: ISOLATE 2: LIST
3: SET 4: TEST
1: SLC DEvices 2: ONBOARD CIRCUITS
3: BACKPLANE 4: CONTROL MODULES
5: GLOBAL ISOLATE 6: MACROS
7:NETWORK
1: LOCAL NODE 2: REMOTE NODE
ENTER REMOTE NODE NUMBER:
ISOLATE/DE-ISOLATE NETWORK NODES
1: ISOLATE 2: DE-ISOLATE *
