Parts List
P/N 06-237058-001 8-3 February 2012
Spare Parts
(continued):
Power
Supplies and
Standby
Batteries
76-800030-002
Expansion Power Supply, 5.4 A (with wiring harness to PMU Board)
76-800030-001 Replacement Power Supply, 5.4 A (without wiring harness to PMU Board)
76-800030-004
Power Management Unit (PMU) Board
76-800030-005
Power Supply Assembly Mounting Bracket
76-800030-003
Add-on Power Supply/PMU Assembly (includes 1 Power Supply, PMU
Board, Bracket and mounting hardware -- for mounting in Tier #2 or Tier #3 of
Main Enclosure or for mounting in any tier of Expansion Enclosure)
76-800030-007 Replacement Fuse Kit for PMU Board
76-800031-004 PMU Audible Trouble Sounder Add-On Kit
75-100000-001 PS-6, 24 Vdc, 6 A Power Supply with red enclosure
75-100000-002 PS-8, 24 Vdc, 8 A Power Supply with red enclosure
75-100000-003 PS-EXP Plug-in Expansion Module for PS-6 and PS-8 Power Supplies
06-115915-013 Battery, 12 Vdc, 7-AH (order 2 for 24V)
06-115915-047 Battery, 12 Vdc, 12-AH (order 2 for 24V)
06-115915-046 Battery, 12 Vdc, 17/18-AH (order for 24V)
89-100052-001
Battery, 12 Vdc, 35-AH (order 2 for 24V - requires Large Capacity
Battery Cabinet)
76-100010-001 Large Capacity Battery Cabinet, Red
76-800030-006
Battery Tray (fits on bottom tier of Main or Expansion Enclosures-provides
access to bottom knockouts)
Misc.
76-800000-001
Installation Hardware, universal
76-800000-006
Inter-Cabinet Harness Kit (for expansion enclosure)
76-800000-005
Bezel for Enclosure Door (fits both Main Enclosures)
76-800000-002
Plexiglass Window, standard
76-800000-003
Plexiglass Window, for use with integrated LED Annunciator
06-220314-001
Spare Lockset/Key for 3-Tiered and 2-Tiered Main and Expansion Enclosures
06-220314-002
Spare Lockset/Key for Large Capacity Battery Cabinet
06-129924-001
Spare Lockset/Key for Remote Enclosure
76-800400-001
PEGAsys Control Unit Retrofit Kit (Includes ARIES NETLink hardware
mounting frame, bracket, compatible door and installation hardware)
70-411001-005
EOL Resistor Kit, 10 K, 0.5 W, package of 10
76-800000-004
In-Line Releasing Device (used for CLASS-A Power-Limited Solenoid-Based
Releasing Devices)
06-220023-001
In-Line Releasing Device (used for CLASS-B Power-Limited Actuator-Based
and Solenoid-Based Releasing Devices)
06-220297-001
EOL Module, RS485 Circuit (terminates up to four Expansion Card Cages)
76-800500-001
City of Chicago Stand-Alone Control Box
Category
Part
Number
Part Name
