List of Agency Listed Compatible Devices
P/N 06-237058-001 C-3 February 2012
A
To determine the total wire length, you must calculate both the to and from distance. For example, a 300 foot length
of wire means a total length of 600 feet as travel down the wire and back must be taken into account.
B
Must be used in conjunction with Microswitches P/N 87-120039-001, 87-120039-501 or 87-120047-001 for
momentary operation.
Table C-3. Releasing Devices - Actuator-Based
* The circuit resistance for this device must be 10 + 1 ohms. The firing current will be 2.5 Amps.
Device Model and
Part Number
I
(Max.)
Amps
Resistance
(Min.)
Ohms
“On” Time
12
AWG
14
AWG
16
AWG
18
AWG
Max.
No.
per
R-NAC
Circuit
Max.
No.
per
RRM
Agency
Kidde-Fenwal
Sol. P/N
81-100000-001
0.440 59.0 Steady 2300 1460 915 570 1 1 or 2 UL, FM
Kidde-Fenwal Electric
Control Head
Model 897494
P/Ns 897494-000 and
WK-897494-000
1.50 15.9 Steady 380 240 140 — 1 1 UL, FM
Kidde-Fenwal Electric
Control Head
Model 897494
P/Ns 897494-530 and
WK-897494-530
1.50 15.9 Steady 380 240 140 — 1 1 UL, FM
For FM Systems:
Kidde-Fenwal
Sol. P/N
06-118329-001
0.225 108.0 Steady 3000 2000 1200 800 1 1 or 2 FM
Marioff
3-101-46A/2
(D21070)
0.92 26.0 Steady 483 327 190 — 1 1 FM
FM Group A 0.458 52 Steady 1440 760 480 340 1 1 FM
FM Group B, D 0.7 34 Steady 940 500 300 220 1 1 FM
FM Group E, G 0.42 57 Steady 1570 760 525 370 1 1 FM
FM Group F Skinner 24 Vdc, 22 Watt Solenoid 7312BN4TNLVNOC322C2 1 1 FM
FM Group I Victaulic 24 Vdc, 8.7 Watts, 364 mA series 753-E Solenoid 1 1 FM
FM Group J Viking Model No. 11591, 11592, 11595, and 11596, 24 Vdc, 10 Watts 1 1 FM
FM Group K Viking Model No. 11601, 11602, and 13215, 24 Vdc, 9 Watts 1 1 FM
Device
I (Max.)
Amps
Resistance
(Min.) Ohms
“On” Time
Max. Number per
R-NAC Circuit
Agency
83-132500-500 * 0.9 Momentary 1 FM
83-131082-001 * 0.9 Momentary 1 FM
Table C-2. Releasing Devices - Solenoid-Based
Wire Length (ft.)
Note: Wire length is total wire
A
To Next Page
