ARIES NETLINK For City Of Chicago Applications
February 2012 G-4 P/N 06-237058-001
3. Apply three (3) blank labels over the control unit’s indicator and keys listed below as shown in
Figure G-4. These keys should not
be used by the operator, in accordance with the AHJ:
– DRILL (Hold for Lamp Test) Operator Control Key
– SIGNAL SILENCE Operator Control Key
– Signal Silenced LED
Figure G-4. Keypad/Display Label Placement
Cover the SIGNAL
SILENCE Key.
Operator Control Keys
Cover the
SIGNAL
SILENCED
indicator.
Cover the DRILL
Key.
LEDs
