February 2012 1-32 P/N 06-237058-001
RELAY CARD Includes four (4) Form C Programmable Relays; no limit on number of Relay
cards in fully expanded system (if slots available)
Contact Rating: 3.0 A @ 24 Vdc (resistive)
3.0 A @ 120 Vac (resistive)
CITY TIE CARD Includes three (3) output circuits to connect to Municipal Tie inputs;
Maximum of 1 card in fully expanded system
Local Energy Type: 24 Vdc nominal @ 550 mA maximum
Supervised for opens and ground faults
Shunt-Type Master Box: 24 Vdc nominal @ 5 A maximum
Reverse Polarity Type: 24 Vdc nominal @ 100 mA maximum
DIGITAL ALARM
COMMUNICATOR
TRANSMITTER (DACT)
CARD
Operating Voltage/Current: Nominal 24 Vdc @ 37 mA
Electrical Interface PSTN line using a RJ45X phone jack
Protocols SIA DC-05-1999.09 Ademco Contact ID
SIA DC-03-1990.01 (R2003.10)
Digital Alarm
Communicator Receivers
(DACRs):
Compatible with Sur-Gard System I, Sur-Gard System III and Osborne Hoffman
Model 2000E
NETWORK INTERFACE
CARD (NIC)
Allows up to 64 control units to be networked; Maximum of 1 card per node.
Operating Voltage/Current: Nominal 24 Vdc @ 63 mA
Interconnecting Wiring
Type
AWG 18, twisted, shielded pair
CLASS-B, Style 4 or CLASS-A, Style 7
Maximum Recommended
Length
4,000 ft. (1.219 m)
Data Ports EIA/TIA-485
Baud Rate 38,400 baud
INTERNET
COMMUNICATIONS
MODULE (ICM) CARD
Maximum of 1 card in fully expanded system
Operating Voltage/Current: Nominal 24 Vdc @ 42 mA
Connector: RJ45 (Ethernet)
