Kidde Fire Systems ARIES NETLink User Manual

P/N 06-237058-001 1-35 February 2012
MCB ON-BOARD NACs (continued from previous page)
Max. Supervisory Current: 5mA
Maximum Output Current: Non-Synchronized: Synchronized:
2.0 A 1.5 A
Maximum Output Circuit
Terminal Voltage:
28 Vdc 28 Vdc
Minimum Output Circuit
Terminal Voltage:
20 Vdc 20 Vdc
ON-BOARD SIGNALING
LINE CIRCUITS (SLCs)
MCB includes two (2) SLC Circuits.
Refer to Specifications for SLC Expansion Card
REMOTE DISPLAY
CONTROL MODULE (RDCM)
Maximum of 15 Remote Display Control Modules supported. The total number
of remote devices cannot exceed more than 31 total addresses (30 if integrated
LAM is included in system).
DC Power Input: 24.0 Vdc @ 150 mA maximum
Input Capacitance: 100 F max.
PMU Trouble Relay Input: short = normal; open = fault
Synch In/Out: 3.3 Vdc Logic - for local connections to RDCM and LAM Modules only
RS485 Input/Output: EIA/TIA-485, AWG 18, twisted unshielded pair
4,000 ft. (1,219 m) maximum wire length
Use low capacitance cable – maximum 15pF per ft.
REMOTE LED
ANNUNCIATOR MODULE
(R-LAM)
Maximum of 16 Remote LED Annunciator Modules supported. The total number
of remote devices cannot exceed more than 31 total addresses (30 if integrated
LAM is included in system).
DC Power Input: 24.0 Vdc @ 150 mA maximum
Input Capacitance: 100 F max.
PMU Trouble Relay Input: short = normal; open = fault
Synch In/Out: 3.3 Vdc Logic - for local connections to RDCM and LAM Modules only
RS485 Input/Output: EIA/TIA-485, AWG 18, twisted unshielded pair
4,000 ft. (1,219 m) maximum wire length
Use low capacitance cable – maximum 15pF per ft.
FIBER OPTIC CONVERTER
MODULE
Allows up to 64 control units to be networked; mounted externally from control
unit
Multi-mode cable type 62.5/125 μm duplex fiber-optic
Single-mode cable type 8.3/125 μm duplex fiber-optic
Max. Recommended Length multi-mode: 1 mile (with no more than 6.4 dB/mile cable attenuation)
single-mode: 12 miles (with no more than 1.66 dB/mile cable attenuation)
Enclosure Dimensions 13 x 7-1/2 x 2 in.
Fiber Optic Connections Type “ST”
Electrical Connections UL-recognized Terminal Blocks for wire size 12 - 30 AWG
Data Ports EIA/TIA-485
