Installation

P/N 06-237058-001 2-15 February 2012

F i g u r e 2 - 1 1 . A C C o n n e c t i o n s t o P M U B o a r d

(shown without AC Voltage Protection Cover, Standoff, Snap-On Suppression Filter and

PMU Ground Wire Assembly)

Figure 2-12. AC Voltage Protection Cover (prohibits access to AC Power input terminals)

Ground (Green) Wire Connection

Earth Ground stud

Neutral (White) Wire connection

Line (Black) Wire connection

Place Snap-On Supression

Filter, P/N 06-115904-087,

around these two wires

(networked control units only)
