Kidde ARIES

August 2013 3-26 P/N 06-236530-001
3-2.5.2.3.12 How to View the Values of the Battery Voltage and Current
Purpose: to view the latest current and voltage values of the battery.
Note: This command can only be used if battery supervision is enable.
See Paragraph 3-2.5.2.4.60.
3-2.5.2.3.13 How to Ascertain that the Standby-Battery is being Recharged
Purpose: To determine if the standby battery is being recharged
3-2.5.2.3.14 How to List the HSSDs on the IIM
Purpose: To view the registered High-Sensitivity Smoke Detectors
(HSSDs) on the Intelligent Interface Module (IIM)
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password; Press “Enter” Key Gain access to menus
3 Press 2 Key Enter List-Menu branch
4 Press "Scroll" Key Twice Access additional options
5 Press 7 Key Access "Voltages" option
6 Press 3 Key Select “Battery Charge”
The battery voltage and current readings display.
7 Press "Backspace” Key (as required) Exit Menu System
Step Action Result
1 Press 0 Key Initiate Menu Access
2 Enter Password; press "Enter" Key Gain access to menus
3 Press 2 Key Enter List-Menu branch
4 Press "Scroll" Key twice Access additional options
5 Press 7 Key Access "Voltages" option
6 Press 3 Key Determine if the standby-battery is being
recharged
7 Press "Backspace" Key (as required) Exit Menu System
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password Gain access to menus
3 Press 2 Key Enter List-Menu branch
4 Press "Scroll" Key twice Access additional options
5 Press 8 Key Access "HSD Assignments”
6 Press "Scroll" Key (as required) Move through HSSDs on IIM
Format for display is:
Address Location
Where:
"Address" is the HSSD address
"Location" is the HSSD location
7 Press "Backspace" Key (as required) Exit Menu System
