August 2013 3-66 P/N 06-236530-001
3-2.5.2.4.46 How to Add One or More Control Units to a Network
Purpose: To include additional control units in an existing network or
to start initial network communications between two or more control
units.
Note: This procedure must be performed to start network operations.
Network communications will not begin after all configurations
have been uploaded unless this procedure is performed. Use
Node No. 1 to start initial network communications.
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password Gain access to menus
3 Press 3 Key Enter Set-Menu branch
4 Press "Scroll" Key Access additional options
5 Press 6 Key Select "Network" option
6 Press "Scroll" Key Access additional options
7 Press 4 Key Select "Add/Remove Nodes”
8 Press 1 Key and then press "Enter" Key to confirm
selection.
Select Add Node
9 Use keypad to enter single node or range of
nodes and press "Enter" Key to confirm selection.
Specify node(s) to be added and execute
procedure
10 Press "Backspace" Key (as required) Exit Menu System
11 Wait until "Initializing Configuration" message
disappears from the display.
Initialization complete
