P/N 06-236530-001 3-67 August 2013
3-2.5.2.4.47 How to Remove One or More Control Units from a Network
Purpose: To permanently remove control units from an
existing network.
CAUTION
Check the system programming to ensure that all other networked control units
do not reference the removed control unit(s). For example, if Node 2 was
removed, be sure that all other networked control units that reacted to
initiating signals from this control unit have this node number removed from
their event-output-control programs. See Configuration Program User’s Guide
for event-output-control programming.
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password Gain access to menus
3 Press 3 Key Enter Set-Menu branch
4 Press "Scroll" Key Access additional options
5 Press 6 Key Select "Network" option
6 Press "Scroll" Key Access additional options
7 Press 4 Key Select "Add/Remove Nodes"
8 Press 2 Key and then press "Enter" Key to confirm
selection.
Select Remove Node
9 Use keypad to enter single node or range of
nodes and press "Enter" Key to confirm selection.
Specify node(s) to be removed and execute
procedure
10 Press "Backspace" Key (as required) Exit Menu System
11 Wait until "Initializing Configuration" message
disappears from the display.
Initialization complete
