3-2.5.2.4.62 How to Register an Intelligent Interface Module (IIM)
Purpose: To inform the ARIES Control Unit that it will be configured
with an Intelligent Interface Module. The IIM must be registered in the
control unit's configuration memory to work correctly.
Note: The IIM is also automatically registered when included in a
configuration upload via the ARIES Configuration Program.
CAUTION
The IIM Registration Procedure shall not be used to configure the HSSDs
connected to the IIM. This is primarily a procedure to store the IIM in the
ARIES's configuration memory. The HSSDs connected to the IIM shall be
configured with the LaserNET Configuration Program.
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password Gain access to menus
3 Select the local node then press “Enter” or a
select a remote node number, press “Enter” then
enter the remote node’s password.
Access applicable control unit (if networked
system)
4 Press 3 Key Enter Set-Menu branch
5 Press "Scroll" Key twice Access additional options
6 Press 8 Key Select "HSDs" option
7 Press 1 or 2 Key to select the port the IIM is
connected to and then press “Enter”
Select “RS232A” or “RS232B”
Assign port to IIM
8 Press "Backspace" Key (as required) Exit Menu System
9 Wait until "Initializing Configuration" message
disappears from the display.
Initialization complete
