August 2013 3-78 P/N 06-236530-001
3-2.5.2.4.63 How to De-Register an Intelligent Interface Module (IIM)
Purpose: To remove an Intelligent Interface Module from the ARIES
Control Unit's configuration memory.
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password Gain access to menus
3 Select the local node then press “Enter” or a
select a remote node number, press “Enter” then
enter the remote node’s password.
Access applicable control unit (if networked
system)
4 Press 3 Key Enter Set-Menu branch
5 Press "Scroll" Key twice Access additional options
6 Press 8 Key Select "HSDs" option
7 Press 3 Key Select register HSDs
8 Use keypad to enter single HSSD or range of
HSSDs to register.
Press "Enter" Key to confirm selection.
Specify single HSSD or range of HSSDs to be
registered
9 Press "Backspace" Key (as required) Exit Menu System
10 Wait until "Initializing Configuration" message
disappears from the display.
Initialization complete
