Kidde ARIES

P/N 06-236530-001 3-15 August 2013
3-2.5.2.2.4 How to De-Isolate Control-Unit-Based Outputs
Purpose: To enable previously-isolated control-unit-based outputs to
execute activation instructions issued by the ARIES Control Unit.
3-2.5.2.2.5 How to Isolate High-Sensitivity Smoke Detectors (HSSDs)
Purpose: To prevent initiating and trouble signals from selected HSSDs
connected to an IIM from being processed and acted upon by the
ARIES Control Unit.
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password; Press “Enter” Key Gain access to menus
3 Press 1 Key Enter Isolate-Menu branch
4 Press 2 Key Select "Outputs" option
45 Press 1 Key for NACs or
Press 2 Key for Release Circuits or
Press 3 Key for Combo Circuits
Press 4 Key for Relays
Select output to de-isolate
6 Use keypad to enter single output or range of
outputs to de-isolate.
Press "Enter" Key to confirm selection.
Get prompt to Isolate or De-Isolate
7 Press 2 Key and then press "Enter" Key to confirm
selection
Execute De-Isolation Routine for single output or
range of outputs entered in Step 6.
8 Press "Backspace" Key (as required) Exit Menu System
Step Action Result
1 Press 0 Key Initiate menu access
2 Enter Password Gain access to menus
3 Press 1 Key Enter Isolate-Menu branch
4 Press "Scroll" Key Access additional options
5 Press 7 Key Select "HSDs" option
6 Use keypad to enter single HSSD or range of
HSSDs to isolate.
Press "Enter" Key to confirm selection
Get prompt to Isolate or De-Isolate
7 Press 1 Key and then press "Enter" Key to confirm
selection.
Execute Isolation Routine for single HSSD or
range of HSSDs entered in Step 6.
8 Press "Acknowledge" Key Silence buzzer and change Supervisory LED from
flashing to steady
9 Press "Backspace" Key (as required) Exit Menu System
