52
01/13424999386
Connection to manual call points
Number of connections: 2
Voltage: 20 V DC
Electricity: max. 60 mA, 100% CDF
Terminal: max. 1.5 mm², spring-loaded terminal
Line monitoring: Active end module/2 (AE/2)
Max. number of manual call points: 10 per connection
Emergency power supply Yes
Connection to automatic detectors
Number of connections: 2
Voltage: 20 V DC
Electricity: max. 60 mA, 100% CDF
Terminal: max. 1.5 mm², spring-loaded terminal
Line monitoring: Active end module/2 (AE/2)
Max. number of automatic detectors: 20 per connection
Emergency power supply Yes
Connection to FAS
Number of connections: 2
Voltage: 20 V DC
Electricity: max. 60 mA, 100% CDF
Terminal: max. 1.5 mm², spring-loaded terminal
Line monitoring: Monitoring module UEB3-2K7-AE
Emergency power supply Yes
Tripping contact NO contact
Wind/rain sensor output
Voltage: 20 V DC
Electricity: max. 100 mA, 100% CDF
Terminal: max. 1.5 mm², spring-loaded terminal
Line monitoring: No
Max. number: 1, Type WRM2 and RM2
Emergency power supply No
Floating contacts 3 x changeover contact; default functions: Fault, trip,
wind/rain signal
Contact loading: max. 30 V / 1 A per contact (ohmic load)
Separate voltage output
Voltage: 27 V DC
Electricity: max. 4 A (available for 10 s),
Terminal: max. 2.5 mm², spring-loaded terminal
Note: When used, 4 A must be deducted from the total current output of
channels
1 + 2. Thus K1 + K2 = 16 A
Emergency power supply No
Mechanical properties
Dimensions: 300 mm x 400 mm x 132 mm
Weight: approx. 5.9 kg
Connection and Operation
Connection: See technical documentation
Ventilation function on mains failure: No, ventilation barred
Safety function on mains failure: Yes, automatic closing of the windows, ventilation barred and SHE
remains active, other functions via DIP switches
