Kingspan EasyConnect+ - Technical Data Overview

51
01/13424999386
Electricalfeatures
Power supply facility
Function class: ELV / Class A
Control type: Type D
Primary power source: Mains
Secondary power source: Battery
Maximum interruption time
between the power sources: < 100 ms
Primary power supply
Power pack supply voltage: 100 V - 240 V AC; 47 Hz - 63 Hz, (±10 %), with separate fuse
System voltage: 27 V DC (nominal) (-30 % / +10 %)
Power consumption: 560 W at 20 A current output
Power pack current consumption: 2.23 A (230 V AC), 5.56 A (100 V AC)
Power consumption (standby): < 5 W
Monitoring: Yes, detection of failure of the 230 V AC mains supply
Terminal: Screw terminal, max. 2.5 mm² (solid 4 mm²)
Mains fuse: F1, 10 A, safety fuse
Secondary power supply
Battery: 7.2 Ah, 2 x 12 V with deep-discharge protection with low voltage,
monitoring for wire breakage and fuse failure, operating time 4 years
Battery type: Lead gel with VdS approval
Emergency power operation: 72 hours, reduced if magnetic clamps are connected
Standby current (current during
battery operation): 55 mA to DIN EN 12101-10 (with connection of max.
20 SHE manual call points and 40 automatic detectors)
Currentoutputafter72hin
emergency power operation: 20 A for 180 sec. to DIN EN 12101-10
Maximum current output: 20 A (with disconnected primary power supply)
Charging time: 20 h for emergency power supply
Monitoring: yes, cyclic
Fuse:
F3, 20 A, FKS
Output
Voltage: 27 V DC (-30%/+10%)
Power:     Pmax=540W;Pmin=0W
Ripple: Drives: < 1%
Magnetic clamps: < 1%
Current (rated): Channel 1:
Drives max.16 A at 30% CDF (output with separate fuse)
Magnetic clamps max. 6 A at 100% CDF (referred to 10 minutes)
Channel 2:
Drives max.16 A at 30% CDF (output with separate fuse)
Magnetic clamps max. 6 A at 100% CDF (referred to 10 minutes)
Channels 1 and 2 together:
Drives max. 20 A at 30% CDF (output with separate fuse)
Magnetic clamps max. 12 A at 100% CDF (referred to 10 minutes)
Opening / closing operation: Voltage pole reversal
Pause time during pole reversal: approx. 300 ms
VdS function retriggering: Yes, reversing of direction of travel every 2 minutes,
     duringtherst30minafterSHEactivation(toensureopening
if dome lights, skylights, etc. are iced)
Automatic activation OPEN/CLOSE
direction: SHE mode without timing after 3 minutes
SHE mode with timing after 30 minutes
Ventilation mode after 3 minutes
Line monitoring: Line monitoring via active motor monitoring module
Terminal: max. 6 mm², screw terminal
Fuse: Drive fuse channel 1: F4, 15 A, FKS
Drive fuse channel 2: F5, 15 A, FKS
3 Technical Data
EasyConnect+
EN
