WARNING
If trying to lift an object with
excessive weight by the 3-point
hitch while the tractor is not
equipped with proper front suit
case weights, the front wheels
may be lifted instead, leading
to roll over. Make sure to fol-
low the specications for use.
•
DRAFT CONTROL (IF APPLICABLE)
(1) Draft Control Lever
(A) Lowering
1. The draft control function is used
to prevent the wheels from rotating
idle and the engine from stopping
due to excessive draft load when
the tractor is used for work which
requires a lot of draft, such as
plowing.
td2O522a
(1) Top Link
2. The draft function is activated
when the top or middle hole on the
top link of the 3-point hitch is used.
The top hole is for sensitive draft
control.
3. To keep the plowing depth shal-
low, put the draft control lever to
the rear (Shallow) position. The
plowing depth tends to become
deeper naturally by outer condi-
tions. When the load increases by
td2O532a
To Next Page
