the increase of the plowing depth
while the draft control lever is set
to the “Shallow” position, the plow-
ing depth is maintained as shal-
low because the reaction force is
transferred to the internal system
via the top link and the lifting arm
is automatically lifted.
4. To keep the plowing depth deep,
put the draft control lever to the
front (Deep) position.
5. The position of the draft control
lever should be different based
on the condition of soil to keep
the plowing depth constant. When
working on a new eld, it is recom-
mended to put the draft control
lever to the proper position for the
desired plowing depth and lock the
lever with the lock bolt.
6.
When using an implement which
requires no draft function, such as a
rotary tiller and mower, use the bot-
tom hole on the top link and put the
draft control lever in any position.
CAUTION
If the lifting arm is properly
operated but abnormal noise
is still heard, the hydraulic
system may be malfunction-
ing. In this case, let the engine
idle for an 10 to 15 minutes
additionally and then try to
start the engine again. If the
problem is still present, con-
tact your local KIOTI Dealer.
•
7.
However, if the draft control lever is
pushed forward to its end, the low-
est position of the lifting arm can be
lowered a little. On the other hand,
if the lever is pulled back to its end,
the highest position of the lifting
arm can be raised a little.
CAUTION
The implement may shake up
and down as the draft sensor
is under impact when the trac-
tor is passing over irregular
ground with the middle or low-
est top link hole selected. In
this case, put the draft control
lever to the “Deep” position
to decrease the sensitivity of
the draft function or select the
highest top link hole.
If the tractor has been stored
for a long period of time or
the transmission fluid is just
changed, abnormal noise may
be heard and the hydraulic
lifting arm may be inoperable
temporarily. In this case, let the
engine idle for 3 to 4 minutes.
•
•
