1.3 Nameplate
The nameplate depicted below is attached to the side of the servo amplifier.
The information described below is printed in the individual fields.
1.4 Instrument description
1.4.1 Package supplied
When you order a SERVOSTAR 600 series amplifier, you will receive:
— SERVOSTAR 6xx
— mating connectors X3, X4, X0A, X0B, X7, X8
The mating SubD connectors and motor connector X9 are not part of the package!
— Assembly, Installation and Setup Instructions
— Online documentation on CD-ROM
— Setup software DRIVE.EXE on CD-ROM
Accessories:
(must be ordered separately)
— AC synchronous servomotor (linear or rotary)
— motor cable (pre-assembled), or both motor connectors separately, with motor cable as a
cut-off length
— feedback cable (pre-assembled, see application note “Cables and connectors”) or both
feedback connectors separately, with feedback cable as length
— motor choke 3YL-20 (ð p.90), for cable length above 25m
— external regen resistor (ð p.73)
— communications cable to the PC(ð p.52) or Y-adapter (ð p.57) for setting parameters of up
to 6 servo amplifiers from one PC
— power cable, control cables, fieldbus cables (as lengths)
SERVOSTAR
®
601...620 Installation Manual 13
Kollmorgen 03/04 General
Typenbezeichnung
Spannungsversorgung
Model Number
Power Supply
Ser. Nr
Nennstrom
Ser. No.
Nom. Current
Bemerkung
Schutzart
Comment
Encl.Rating
Danaher Motion GmbH
Wacholderstr. 40-42
D-40489 Düsseldorf
www.DanaherMotion.net
Customer Support
Europe Tel. +49 (0)203 / 99790
Italy 3 36 594260
North America 1 80 777-3786
Tel. + 9 (0) 2 /
Tel . + ( 0)
CONNECT-module
and options
Serial numberServo amplifier type
Electrical supply
Installed load
Output current
in S1 operation
Enclosure Rating
